Cyrus Audio CDT-XR

Cyrus Audio Audio CDT-XR hos Lefflers Ljud & Bildupplevelser i Norrköping

OBS CD-Transport!

Referens CD-transport baserad på CD XT Signature men med de senaste årens
utveckling på insidan. Precis som CDI-XR har man här Cyrus egna mekanik,
"servo evolution". Man har jobbat med att sänka bruset vilket gör att
man lyfter fram upplösning och detaljer på ett helt nytt sätt. Man har också en
helt omarbetat strömförsörjning. Men framföra allt sitter det en ny omklockare
innan signalen lämnar lådan som garanterar en perfekt utsignal.
CDT-XR är förberedd för PSU-XR.

Cyrus CDt-XR features and benefits
Servo Evolution
The Cyrus philosophy for reading CD has always been the
same - read it once and read it accurately. The latest iteration
of Cyrus SE technology in the CDt-XR does exactly this,
streaming the data from the disc to the audio processing
circuitry with precision and accuracy.
Pure Transport
With no built-in DAC, nor the requirement to drive it, the CDtXR works purely as a digital transport. The absence of any
DAC or analogue circuitry allows design of the CDt-XR to be
focussed purely on data retrieval, state-of-the-art reclocking
and a high performance digital output.
Connectivity
The CDt-XR includes both optical and SPDIF coaxial digital
outputs fed from a dedicated digital audio output driver.
Power supply design
As with any CD player, the performance of digital CD
transports benefits greatly from high quality, stable power
supplies. In the case of the CDt-XR, the digital control circuits
run from a dedicated, high-efficiency power supply. A high
capacity linear supply feeds separately to the SE circuit, the
digital master clock, the digital audio output driver, the PLL
master clock and the drive motors through independent
regulation channels.
PSU-XR port
The CDt-XR includes a port for the all-new PSU-XR power
supply upgrade. Thirty years ago Cyrus broke new ground
with the introduction of the PSX-R, the first ever regulated
power supply upgrade that automatically adapted to match
perfectly the power requirements of any connected product.
The PSU-XR raises the bar by sourcing no less than five
independent regulated supplies in a single box. For the
CDt-XR the PSU-XR is employed to reduce dynamic loads on
the internal power supplies and enable these to run under
more stable conditions.
Configurable options menu
A new menu system makes the CDi-XR customisable yet
easy to set up. The tree-style navigation structure has display,
time-out, and system configuration options. Menu settings are
quick and simple to select.

Cyrus CDt-XR Specifications
Digital CD transport
Servo Evolution technology
Optical and coaxial outputs
PSU-XR upgrade port
User upgradable firmware
iR14 Remote control included
Dimensions (H x W x D) – 73 x 215 x 360 mm
Weight – 3.7kg
