QED REFERENCE XLR 40 Analouge

Referens XLR 40 bygger på det flerfaldigt prisbelönta Audio 40-sortimentet, nu tillgängligt i XLR-form.

XLR 40 är designad främst för låg kapacitans eftersom detta har identifierats av QED som en viktig faktor som leder till en högtrohetsupplevelse. Ytterligare steg har vidtagits för att eliminera minimala tidsfel i kabeln genom att använda en speciell flytande Zn/Mn ferritmantel tillsammans med användningen av QED:s unika 'Tri-Conductor'-teknik som reducerar signal-till-jordkapacitansen till försvinnande låga nivåer.

EATURES AND BENEFITS

Award Winning Heritage

Reference XLR 40 builds on the multi-award winning Audio 40 range of products, now available in XLR form. QED have joined forces with world renowned professional audio connector supplier Neutrik (UK) to bring you an innovative new XLR balanced interconnect cable with legendary build quality and reliability.

Professional Standard Neutrik plugs

Neutrik XX-14 Nickel Series XLR gold plated connectors are provided as standard with Reference XLR 40 cables. These connectors are rugged and reliable and are the connector of choice for audio professionals around the world. They are particularly suited to QED's Tri-ConductorTM geometry due to the additional ground spring contacts which make for better shell ground continuity for the unique electrostatic screen which is only connected at the source end of the cable.

Just Listen

Silver plated conductors, LDPE dielectrics and legendary build quality combine to create audible sonic improvements. We urge you to compare Reference XLR 40 not only to your favourite cable but also alternative brands and models at any price!

Floating ferrite jacket

Absorbs high frequency noise signal components outside the audio band. When measured using high frequency measurement equipment, Audio 40 products convey a comparably cleaner and tighter signal pattern when its special Zn/Mn ferrite jacket is present.


Unique Tri-conductor Technology

QEDs unique Tri-Conductor technology uses a third Silver plated 99.999% OFC conductor which is integrally twisted alongside the similarly constructed signal pair to carry the ground return currents. This reduces signal to ground capacitance to vanishingly low levels affording the cable improved common mode rejection of mains hum pickup over ordinary "hot cold and screen" cables. This geometry is particularly effective in pro hi-fi audio applications when connecting pre and power amps using balanced cables.

Specifications

Silver Plated 99.999% Oxygen Free Copper (SPOFC) 24 AWG
Tri-Conductors with foamed PE dielectric
• Unique Tri-conductor Technology
• OFC shield giving 100% electromagnetic screening
• Zn/Mn ferrite Jacket
• Neutrik XX-14 Nickel Series XLR gold plated connectors
• Parallel Capacitance: 35 pF/m
• Inductance: 0.8 μH/m
• Loop resistance: 0.130 Ω/m
• Dissipation Factor: 0.0001
• Conductor Section 0.25 mm2
